$380.00
ALL NEW!
Works with all versions of the Umarex Gauntlet 1, 2, 30 Cal, Bolt action or SL variants*!
500cc/.5L CE Certified CF Tank
Shaves off 1/2 a pound of weight on the Gauntlet 2/Gaunlet 30, compared to the stock aluminum tank and regulator configuration.
Includes the UX/Ninja X-Regulator.
The CF Tank is CE Certified, made to ISO 11119-3 standard. The cylinder has a seamless aluminum alloy 6061 liner wound with high-strength Japan-imported carbon fiber and glass fiber reinforced plastic full composite layers and subjected to an autofrettage pressure. This 4500 PSI carbon fiber bottle is 500cc and is gorgeous on the Gauntlet series of PCP.
Operating Pressure Recommendations
Gauntlet 1:
.177/.22 Stock operating pressure 1100PSI Max Recommended pressure is 1400PSI.
.25 Caliber Stock operating pressure 1900PSI Max Recommended pressure is 2300PSI.
Gauntlet 2/SL:
.22 Stock operating pressure 1900PSI Max Recommended pressure is 2150PSI.
.25 Caliber Stock operating pressure 2100PSI Max Recommended pressure is 2400PSI.
Gauntlet 30/30SL:
.30 Stock operating pressure 2800PSI Max Recommended pressure is 3100PSI.
NINJA REGULATORS ARE MADE IN THE USA!
*Tank shroud must be removed and left off to use this setup.
Direct replacement for the aluminum tank and regulator that comes on the Gauntlet 1, 2, G30, SL, or Bolt.
The custom unit can be ordered with any custom regulator output pressure in 100-PSI increments.
NOTE: The regulator output will be +/- 50 PSI of the requested output.
| Weight | 32 oz |
|---|---|
| Dimensions | 15 × 2.25 × 2.25 in |
| Regulator Output | 1100 PSI, 1200 PSI, 1300 PSI, 1400 PSI, 1500 PSI, 1600 PSI, 1700 PSI, 1800 PSI, 1900 PSI, 2000 PSI, 2100 PSI, 2200 PSI, 2300 PSI, 2400 PSI, 2500 PSI, 2600 PSI, 2700 PSI, 2800 PSI, 2900 PSI, 3000 PSI, 3100 PSI |
You must be logged in to post a review.
Gauntlet Gen: G30/G30SL/G2SL22/G2SL25 500cc CF Tank, Type: With Rail
Gauntlet Gen: G30/G30SL/G2SL22/G2SL25 500cc CF Tank, Type: Without Rail
Hajimoto Flex Reg on 22ci Aluminum 3K for the G1
Introducing a Hajimoto Productions Exclusive offer!
22ci/360cc/.36L Aluminum Tank 3000PSI
Newly redesigned unit
Now has a high pressure and low pressure burst discs!
Flex 22 Configuration For Generation 1 Gauntlet .177/.22 Cal
Stock .177/.22 | 3000/1100PSI Regulator
Flex 22 .177/.22 |3000/700 to 1500PSI
Flex 22 Configuration For Generation 1 Gauntlet .25 Cal
Stock .25 | 3000/1900PSI Regulator
Flex 22 .25 | 3000/1500 to 2300PSI
If you are looking to add an externally adjustable reg to your Gauntlet 2, take a look at swapping your current fixed reg to the Flex reg found HERE
Installs on the Gauntlet with minor tank shroud modifications. (The Gauntlet 2 is shown to give an idea of what modification needs to happen and that is simply a hole drilled in the bottom of the plastic tank shroud for the fill nipple.
A 22ci aluminum 3000PSI cylinder with externally adjustable Ninja Flex Reg for your Umarex Gauntlet1! The volume of air in these 22ci tanks over the 13ci is mind-blowing!
The diameter of the tank is 54-55mm across so a modification to the forearm is required on a Gauntlet 1. I do offer a tank shroud modification service for Gauntlet 1 owners that can be added to a build or provided as a mail-in service.
The Gauntlet 2 forearm slide right over without any issue. Only one access hole needs to be drilled so the fill port is accessible at the bottom.
Consider picking up our extended foster fill adapter to make coupling and filling a breeze.
The Power Flex Combo allows the user to externally adjust the regulator output pressure on the fly with an adjustment range of 800PSI!
When installing the Flex 22 on the Umarex Gauntlet. Tighten the degassed tank and regulator assembly fully to the rifle, then back it off until the fill port is on the bottom and the gauges are left and right. Now fill the bottle with air and all will tighten up solid. Proper alignment will be achieved before the 360° maximum rotation limit is realized.
Comes with a dedicated Spanner Wrench for power adjustment. MADE IN THE USA!
Because of practical limitations, regulator output will be +/- 50PSI (3.5bar) within the requested output.
for .177, .22 and .25 NOT .30
Part fits Umarex Gauntlet 177, .22 or .25. Not compatible with the Gauntlet .30 Caliber.
This part is designed and manufactured by DonnyFL
Hajimoto Productions Regulator Shim Kit For Umarex Gauntlet
I have put together a very easy and complete stainless steel shim kit so you can adjust your Gauntlets Regulator output. The shims that I have included give you a wide range of adjustability to mix and match different thicknesses to get the regulator to output exactly what you want. The shim kit comes with easy to follow instructions which guide you through the process as to what shims you need to add to typically achieve my recommendations for each Gauntlet Caliber.
The shim kit contains:
To take a stock G1 .177/.22 from the stock 1100-1050PSI to my recommended 1350-1400PSI you would add two (2) #5 shims (10).
To take a stock G1 .25 from the stock 1900-1950PSI to my recommended 2100-2200PSI you would add one (1) #3 shim (3).
The included two #2 shims are for minor adjustments if you have a finicky regulator.
DETAILED LESSON/EXAMPLE:
Let’s say your .22 Gauntlets regulator only puts out 1300PSI after installing the two #5’s when it should be 1350 to 1400PSI, you would add one #2 for a total of 12 to help get it there. If after the addition of the one #2, you’re still 50psi short so you would pull out the #2 and use the #3 for a total of 13.
Always use a regulator output tester to confirm the output pressure of your regulator. It is the only safe and sure way to properly adjust the pressure of your regulator.
You have to fill and purge so the Belleville washers settle into the new preload. Be sure to slow fill your bottle the first time only to 500PSI and then purge it, fill slowly a second time to 1000, and then purge fill the final time slowly and watch to be sure the reg has settled and does not exceed your target pressure. If it does exceed your target pressure, stop filling, purge and shim less.
If you rapid fill, there is a good chance you will pop your burst disc.
