$30 to $1000
Hajimoto Productions Gauntlet .30 Service Selector/Builder
Important Information:
This builder is used for G30 OWNERS who understand that they will be sending in their G30 to have modifications performed. If you are looking to purchase any of the parts listed below, you will want to leave SERVICE and use the SEARCH for the PART you want.
So you didn’t know we offered turnkey G30 packages? So you already own a G30 and wish you could get were able to have some of the service modifications that are available on some of our Airgun Packages? Well, we got you covered with this G30 specific Service Builder.
This menu system allows you to select what you want or what you don’t want and when you’re done you have a complete turnkey service request for your Gauntlet .30 Caliber!
- The Gauntlet 30 Caliber
Shortly after your order is received, we will respond with the shipping information as well as what your shipping label needs to contain.
The shipping you pay at checkout is only a placeholder and the actual shipping fees associated with this order will be adjusted so that you only pay what is required once we receive your package and calculate the actual size and weight of your package. In some cases, you will be required to pay more and in others, you will receive a refund.
Please note that this service is exempt from any discount campaigns.
10 in stock
1 in stock
5 in stock
9 in stock
Additional information
Weight | 136 oz |
---|---|
Dimensions | 20 × 10 × 6 in |
You must be logged in to post a review.
Related products
-
Sold out!DISCONTINUED
HP Strip Stak Pak for Evanix Air Speed
$60.00Select optionsEvanix Air Speed Air Stripper and Baffle Stack _
An efficient multiport air stripper that strips and channels air away from the pellet to allow for a more stable and less turbulent pellet launch from the muzzle. Air stripper come with o-ring. The kit also provides variable baffle chambers to help remove both noise and turbulence in the air stream. The end result is a more laminar air stream which reduces projectile instability and as a secondary benefit, reduces the report of the rifle.Replacement Air Stripper 0-ring is 14mm x 1.5mm
-
Sold out!
Evanix Rainstorm II Baffle Stack
$35.00Select optionsEvanix Rainstorm II Baffle Stack
Here is an 8 piece multi-sized baffle stack for the Evanix Rainstorm/Rainstorm II. The HP Baffle Stack strips away turbulent air and sound from the shot signature of the Umarex Gauntlet. The baffles trap sound and air in each cavity and force it to stay in the moderator chamber away from the pellet path.
The Rainstorm HP Baffle Stack requires the non cone STAND OFF to be sized by the user. You will need to sand the STAND OFF down to the required height for your rifle.
The HP Baffle Stack should be installed as follows, from the front, further-est from the barrel, Short/Full/Full/Short/Short/Full/Full/Standoff at the muzzle.Baffles should be pointing towards the breech
<= Towards the breech —— Towards the Muzzle of shroud =>
[░░] <░] <░░] <░░] <░] <░] <░░] <░░] CAP
SO SC NC NC SC SC NC NCSO = STAND OFF
NC = NORMAL CONE
SC = SHORT CONE -
Umarex Gauntlet Regulator Shim Pak
$18.50Select optionsHajimoto Productions Regulator Shim Kit For Umarex Gauntlet
I have put together a very easy and complete stainless steel shim kit so you can adjust your Gauntlets Regulator output. The shims that I have included give you a wide range of adjustability to mix and match different thicknesses to get the regulator to output exactly what you want. The shim kit comes with easy to follow instructions which guide you through the process as to what shims you need to add to typically achieve my recommendations for each Gauntlet Caliber.
The shim kit contains:
- 2 – #5 Shims.
- 1 – #3 Shim.
- 2 – #2 Shims.
(Two #2’s = One #4 | Two #5’s = One #10 | One #5 + One #3 = One #8, and so on)
To take a stock G1 .177/.22 from the stock 1100-1050PSI to my recommended 1350-1400PSI you would add two (2) #5 shims (10).
To take a stock G1 .25 from the stock 1900-1950PSI to my recommended 2100-2200PSI you would add one (1) #3 shim (3).
The included two #2 shims are for minor adjustments if you have a finicky regulator.DETAILED LESSON/EXAMPLE:
Let’s say your .22 Gauntlets regulator only puts out 1300PSI after installing the two #5’s when it should be 1350 to 1400PSI, you would add one #2 for a total of 12 to help get it there. If after the addition of the one #2, you’re still 50psi short so you would pull out the #2 and use the #3 for a total of 13.Always use a regulator output tester to confirm the output pressure of your regulator. It is the only safe and sure way to properly adjust the pressure of your regulator.
You have to fill and purge so the Belleville washers settle into the new preload. Be sure to slow fill your bottle the first time only to 500PSI and then purge it, fill slowly a second time to 1000, and then purge fill the final time slowly and watch to be sure the reg has settled and does not exceed your target pressure. If it does exceed your target pressure, stop filling, purge and shim less.
If you rapid fill, there is a good chance you will pop your burst disc.
