Power Flex Combo 22.5ci Carbon Fiber 4500PSI

Flex reg and 22.5ci/370cc/.37L CE Certified CF Tank
Sale!

Flex reg and 22.5ci/370cc/.37L CE Certified CF Tank

Original price was: $375.00.Current price is: $330.00.

Introducing a Hajimoto Productions Exclusive offer!

22.5ci/370cc/.37L CE Certified CF Tank
Newly redesigned unit
Now has a high pressure and low pressure burst discs!

Installs on the Gauntlet 2 with minor tank shroud modifications, forearm slides right over the carbon fiber cylinder.  Installation video at the bottom of the page.

The CF Tank is CE Certified and made to ISO 11119-3 standard. They have seamless aluminum alloy 6061 liner wound with high strength Japan-imported carbon fiber and glass fiber reinforced plastic full composite layers and subjected to an autofrettage pressure. This included a 22.5ci carbon fiber 4500PSI cylinder with externally adjustable Ninja Flex Reg for your custom build including the Umarex Gauntlet 1 or Gauntlet 2! The massive volume of air in these 22.5ci tanks is mind-blowing!

The diameter of the tank is 54-55mm across so a modification to the forearm is required on a Gauntlet 1. I do offer a tank shroud modification service for Gauntlet 1 owners that can be added to a build or provided as a mail-in service.

Please be careful if you have accessories on any of the M-Lok openings as the screws or MLok fasteners may protrude into the tank area and scratch the tank when the shroud is slid forward or back. We recommend that if you have any MLok accessories installed, you remove them when sliding the shroud on or off. We also recommend covering the brass inserts in the tank shroud with cloth tape to protect your carbon fiber finish.

The Gauntlet 2 forearm slides right over without any issue. Only one access hole needs to be drilled so the fill port is accessible at the bottom. See photo below

Consider picking up our extended foster fill adapter to make coupling and filling a breeze.

The Power Flex Combo allows the user to externally adjust the regulator output pressure on the fly with an adjustment range of 800PSI!

When installing the Flex regulator on the Umarex Gauntlet. Tighten the degassed tank and regulator assembly fully to the rifle, then back it off until the fill port is on the bottom and the gauges are left and right. Now fill the bottle with air and all will tighten up solid. Proper alignment will be achieved before the 360° maximum rotation limit is realized.

Comes with a dedicated Spanner Wrench for power adjustment. MADE IN THE USA!

Because of practical limitations, regulator output will be +/- 75PSI to the requested output.

Clear
SKU: HPGNPRFXCBO-22 Categories: , , , , , , ,

Description

When installing the Flex regulator on the Umarex Gauntlet 1 or 2 (G1/G2). Tighten the degassed tank and regulator assembly fully to the rifle, then back it off until the fill port is on the bottom and the gauges are left and right. Now fill the bottle with air and all will tighten up solid. Proper alignment will be achieved before the 360° maximum rotation limit is realized

The Power Flex Combo is a 4500PSI Flex reg installed on a 22.5ci Carbon Fiber 4500PSI Cylinder.

The Flex reg allows for the user to adjust regulator output on the fly while the 22.5ci 4500PSI cylinder means shots galore!

CONFIGURATIONS:
1) – 500~1500 PSI  works well with the .177/.22 Caliber G1
2) – 1400~2400 PSI works well with the G1 .25 Caliber, G2 in .22 or .25 Caliber.
3) – 2100~3100 PSI works well with the Gauntlet .30 Caliber

If the Power Flex is going to be installed on a Gauntlet 1 and the tank shroud is going to be used, the shroud will need to be widened to allow the larger diameter carbon fiber tank to pass through.

The Gauntlet 1 tank shroud modification is offered as a service if you don't want to mess with it yourself.

Comes with a dedicated spanner wrench for adjusting the output of the Flex Reg.

WARNING!  Do not install any Power Flex Combo that exceeds the PCP's operating pressure limit. Damage to the PCP or bodily injury can result.

Please note, that you need to understand what you are buying and if you are not sure, you need to contact us and we will help you make the right selection for your airgun.

Flex Reg is Manufactured by Ninja Paintball.

Additional information

Weight 25 oz
Dimensions 11 × 2 × 3 in
PRESSURE SETTING

G1 .17/.22 – 500~1500PSI Output, G1 .25/G2 .22, .25 – 1500~2400PSI Output, G30 CAL 2100-3100PSI Output

Reviews

There are no reviews yet.

Be the first to review “Power Flex Combo 22.5ci Carbon Fiber 4500PSI”

Related products

  • Shogun 1.6 x 8 inches
    $185.00
    Shogun 1.6 x 8 inches
    $185.00

    THIS IS AN AIRGUN ONLY PART

    This part is designed and manufactured by DonnyFL

    Remember it is recommended that you order your suppressor one size larger for shrouded barrel PCP’s.
    If you have a .22 caliber shrouded barrel PCP, you’ll want to order a .25 caliber suppressor.
    The .177/.22 is for shrouded barrel .177 or direct barrel threaded PCP’s in .22.
    The .22/.25 is for shrouded barrel .22 or direct barrel threaded PCP’s in .25.
    The .25/.30 is for shrouded barrel .25 or direct barrel threaded PCP’s in .30. The exception to this rule is the Gauntlet .30 which is shrouded but because of the unique end cap, marries the barrel and shroud at the end.

    Select options
  • High Travel Valve Stop For Umarex Gauntlet 1 or 2
    $30.00

    Intended for higher power builds

    High Travel Valve Stop For Umarex Gauntlet 1 or 2
    $30.00

    This part replaces part #19 and allows for greater valve dwell producing more power to be produced at higher regulator pressure settings.

    The .22 caliber HTVS for the Generation 1 Gauntlet fits both the .177 and .22.  Do not order Generation 1 HTVS for the Generation 2 Gauntlet, they are not the same



    Select options
  • Umarex Gauntlet Regulator Shim Pak
    $18.50
    Umarex Gauntlet Regulator Shim Pak
    $18.50

    Hajimoto Productions Regulator Shim Kit For Umarex Gauntlet

    I have put together a very easy and complete stainless steel shim kit so you can adjust your Gauntlets Regulator output. The shims that I have included give you a wide range of adjustability to mix and match different thicknesses to get the regulator to output exactly what you want. The shim kit comes with easy to follow instructions which guide you through the process as to what shims you need to add to typically achieve my recommendations for each Gauntlet Caliber.

    The shim kit contains:

    • 2 – #5 Shims.
    • 1 – #3 Shim.
    • 2 – #2 Shims.
      (Two #2’s = One #4 | Two #5’s = One #10 | One #5 + One #3 = One #8, and so on)

    To take a stock G1 .177/.22 from the stock 1100-1050PSI to my recommended 1350-1400PSI you would add two (2) #5 shims (10).
    To take a stock G1 .25 from the stock 1900-1950PSI to my recommended 2100-2200PSI you would add one (1) #3 shim (3).
    The included two #2 shims are for minor adjustments if you have a finicky regulator.

    DETAILED LESSON/EXAMPLE:
    Let’s say your .22 Gauntlets regulator only puts out 1300PSI after installing the two #5’s when it should be 1350 to 1400PSI, you would add one #2 for a total of 12 to help get it there. If after the addition of the one #2, you’re still 50psi short so you would pull out the #2 and use the #3 for a total of 13.

    Always use a regulator output tester to confirm the output pressure of your regulator. It is the only safe and sure way to properly adjust the pressure of your regulator.

    You have to fill and purge so the Belleville washers settle into the new preload. Be sure to slow fill your bottle the first time only to 500PSI and then purge it, fill slowly a second time to 1000, and then purge fill the final time slowly and watch to be sure the reg has settled and does not exceed your target pressure. If it does exceed your target pressure, stop filling, purge and shim less.

    If you rapid fill, there is a good chance you will pop your burst disc.



    Select options
