Here you will find all of our tuning and repair items for all generations of the Umarex Gauntlet including services.
-
$7.00Gauntlet Barrel Baffle Spring
Umarex Gauntlet Baffle Spring
$7.00Select optionsUmarex Gauntlet .177, .22, or .25 Baffle Spring.
Part is not compatible with Gauntlet .30 Caliber
This is the spring that lives in your Gauntlets Shroud. It is required to keep the air stripper on the end of the barrel and allows the baffle or baffle stack to live under tension.
-
Sale!
Original price was: $17.95.$14.00Current price is: $14.00.Stock Umarex Magazine
Umarex Gauntlet Rotary Magazine
Original price was: $17.95.$14.00Current price is: $14.00.Select optionsThe Gauntlet Rotary Magazine advances each pellet with the operation of the bolt on the Umarex Gauntlet PCP air rifle.
Features
- .177 = 12 shots
- .22 = 10 shots
- .25 = 8 shots
- .30 = 7 shots
-
$17.00Gauntlet 1 and Gauntlet 2
Umarex Gauntlet Tune O-ring Kit
$17.00Select optionsHajimoto Productions Tuning O-ring kit for the Gauntlet and Gauntlet 2
Now includes my “NO RING” pellet probe seals as HP-1 rather than the typical high wear donut orings.
I have put together the most common o-rings that fail during a tuning session. Most of the stock o-rings for the internals will gouge when the airgun is disassembled, this kit will allow you multiple attempts should any of the o-rings fail. Please note that the .30 caliber uses completely different internal o-rings than all previous Gauntlet Models including the .30 cal exclusive transfer port orings Which will be bagged as TP.
Some of the NO-Ring seals have the leading edge precision ground.
These tapered / precision ground types need to be installed as shown below
(Images are of the .30 caliber NO RING)
You get:
- 2 of pellet probe NO-ring seals.
- 2 sets of barrel o-rings.
- 2 sets of tank block o-rings.
- 2 of valve body o-rings.
-
$18.50Umarex Gauntlet Regulator Shim Pak
$18.50Select optionsHajimoto Productions Regulator Shim Kit For Umarex Gauntlet
I have put together a very easy and complete stainless steel shim kit so you can adjust your Gauntlets Regulator output. The shims that I have included give you a wide range of adjustability to mix and match different thicknesses to get the regulator to output exactly what you want. The shim kit comes with easy to follow instructions which guide you through the process as to what shims you need to add to typically achieve my recommendations for each Gauntlet Caliber.
The shim kit contains:
- 2 – #5 Shims.
- 1 – #3 Shim.
- 2 – #2 Shims.
(Two #2’s = One #4 | Two #5’s = One #10 | One #5 + One #3 = One #8, and so on)
To take a stock G1 .177/.22 from the stock 1100-1050PSI to my recommended 1350-1400PSI you would add two (2) #5 shims (10).
To take a stock G1 .25 from the stock 1900-1950PSI to my recommended 2100-2200PSI you would add one (1) #3 shim (3).
The included two #2 shims are for minor adjustments if you have a finicky regulator.DETAILED LESSON/EXAMPLE:
Let’s say your .22 Gauntlets regulator only puts out 1300PSI after installing the two #5’s when it should be 1350 to 1400PSI, you would add one #2 for a total of 12 to help get it there. If after the addition of the one #2, you’re still 50psi short so you would pull out the #2 and use the #3 for a total of 13.Always use a regulator output tester to confirm the output pressure of your regulator. It is the only safe and sure way to properly adjust the pressure of your regulator.
You have to fill and purge so the Belleville washers settle into the new preload. Be sure to slow fill your bottle the first time only to 500PSI and then purge it, fill slowly a second time to 1000, and then purge fill the final time slowly and watch to be sure the reg has settled and does not exceed your target pressure. If it does exceed your target pressure, stop filling, purge and shim less.
If you rapid fill, there is a good chance you will pop your burst disc.
-
$20.00HP Baffle Stack For Umarex Gauntlet
$20.00Select optionsPart fits either the original Gauntlet or the Gauntlet 2
THESE BAFFLES CANNOT BE USED INSIDE THE DONNYFL SHORT SHROUD.
-
$30.00 – $35.00Fits Gauntlet 1, 2 even the .30 Cal
HP Barrel Band For Umarex Gauntlet
$30.00 – $35.00Select optionsAvailable in the classic Picatinny rail version or the 15mm thick rail less version.
Fits both the original Gauntlet as well as the Gauntlet 2 including the G30 or G30SL!
-
$30.00Intended for higher power builds
High Travel Valve Stop For Umarex Gauntlet 1 or 2
$30.00Select optionsThis part replaces part #19 and allows for greater valve dwell producing more power to be produced at higher regulator pressure settings.
The .22 caliber HTVS for the Generation 1 Gauntlet fits both the .177 and .22. Do not order Generation 1 HTVS for the Generation 2 Gauntlet, they are not the same
-
$33.00Gauntlet 1 or Gauntlet 2 Mini Magazine
HP Gauntlet, Mini Mag
$33.00Select optionsIntroducing the HP Mini Magazine.
The same reliable design as our expanded magazine but shorter to allow the mag to fit under your optic without the need to adjust or swap out your scope rings.
The HP Mini magazine is designed to fit the Umarex Gauntlet 1 or 2 in .22 and .25 calibers. This magazine extends your capabilities by increasing the number of shots before requiring a reload.
The stands only 40.90mm (1.610″)
The NO LID design means you simply rotate the projectile carousel and drop in each round. There is no need to preload the spring, you are winding the spring during the loading process. This fits under high-scope rings and some medium-scope rings. Your scope may need to be moved forward or back to clear the turret bell, maybe
Features
- An easy to load NO LID design.
- No pre-winding is necessary.
- Easy partial fill design.
- .22 = 13 shots
- .25 = 11 shots
- The magazine height is 40.90mm (1.610″ )
WATCH THE VIDEO BELOW ON HOW TO LOAD MAGAZINE
-
$35.00 – $40.00For Gauntlet .177, .22, .25 and .30 Calibers
Hajimoto’s Gauntlet Expanded Magazine
$35.00 – $40.00Select optionsNow offering two designs. The original NO LOD and the new magnetic removable HP 2.0 design allows for much faster loading.
Here is a high-quality, high-capacity magazine designed to fit the Umarex Gauntlet 1 or 2 in .177, .22, and .25 calibers. This magazine extends your capabilities by increasing the number of shots before requiring a reload. Please remember we stock adjustable height scope rings by WestHunter, EagleVision, and FX, be sure to snag a set if you are worried about clearance issues plus adjustable rings allow you to keep your scope optically center leaving all the turret adjustment-free to use when you need it.
The NO LID design means you simply rotate the projectile carousel and drop in each round. There is no need to preload the spring, you are winding the spring during the loading process. This fits under high-scope rings and some medium-scope rings. Your scope may need to be moved forward or back to clear the turret bell
Features
- An easy to load NO LID design or the new magnetic lidded version.
- No pre-winding is necessary.
- Easy partial fill design.
- .177 – 21 shots which is an increase of 110% more shots over the stock magazine!
- .22 = 17 shots which is an increase of 70% more shots over the stock magazine!
- .25 = 15 shots which is an increase of 37.5% more shots over the stock magazine!
- .30 = 11 shots which is an increase of 57.5% more shots over the stock magazine!
- The magazine height for the .177, .22 and .25 is 50.25MM (1.978″)
- The magazine height for the .30 is 46.20MM (1.820″) Max Slug/Pellet length supported 11.20mm (0.441″)
WATCH THE VIDEO BELOW ON HOW TO LOAD MAGAZINE
-
$45.00for .177, .22 and .25 NOT .30
Umarex Gauntlet Strip Stak Pak (Bundle)
$45.00Select optionsHajimoto Productions Strip Stak Pak for the Gauntlet 1 or 2. Not compatible with the Gauntlet .30 Caliber.
An efficient multiport air stripper that strips and channels air away from the pellet to allow for a more stable and less turbulent pellet launch from the muzzle. The HP Air stripper 2.0 comes with an o-ring. The kit also provides variable baffle chambers to help remove both noise and turbulence in the air stream. The end result is a more laminar air stream which reduces projectile instability and as a secondary benefit, reduces the report of the rifle.BAFFLES CAN NOT BE USED WITH DONNYFL SHORT SHROUD
Because the Short Shroud is cut at a length that is a perfect fit for the air stripper and the spring. There is not any room for the baffles in the DonnyFL Short Shroud.
Air Stripper comes with o-ring and silicone grease for installation.
-
$50.00For G30, G30SL or Any Gen Gauntlet
Gauntlet Barrel Chambering Correction
$50.00Select optionsService to correct the Gauntlet series of PCP’s. Calibers include .177, .22, 25, 30, or the 30SL, hard chambering of slugs issues.
